Jetson Orin UEFI boot sequence: MB1, MB2, TF-A, UEFI, and kernel

The Jetson Orin boot sequence spans five distinct stages before the Linux kernel takes control. Each stage runs at a different privilege level, and failures in early stages (MB1/MB2) require UART debug access to diagnose. Understanding where each stage runs and what it initializes is essential for custom carrier board bring-up and production system hardening.

Key Insights

• MB1 runs from ROM — it cannot be modified — DRAM initialization failures here require board-level debug (oscilloscope on DRAM signals)
• MB2 and TF-A are replaced during flashing — they are written to dedicated QSPI NOR flash partitions; flash.sh updates them
• UEFI applies device tree overlays — the plugin manager reads DTBOs from SPI flash before passing the DTB to the kernel; this is why DTBO changes require flash.sh --no-flash plus tegraflash to update SPI flash only
• extlinux.conf is the most accessible customization point — kernel cmdline, DTB path, and FDT overlays are all controlled here with no reflashing needed
• UART output shows the current boot stage — each stage identifies itself in the serial output; knowing the last visible stage tells you exactly where a boot failure occurred

Boot sequence overview

Power-on
   │
   ▼
MB1 (ROM stage)
├─ Runs from on-chip ROM at EL3
├─ Initializes DRAM (EMC controller)
├─ Loads MB2 from QSPI NOR flash
└─ Transfers control to MB2
   │
   ▼
MB2 (BPMP stage)
├─ Sets up PMIC and power rails
├─ Configures clock tree and PLLs
├─ Establishes security partitions (TrustZone)
├─ Loads TF-A (Trusted Firmware-A) to EL3
└─ Loads UEFI payload
   │
   ▼
TF-A (EL3 Secure Monitor)
├─ Initializes BPMP (Boot and Power Management Processor)
├─ Sets up SMC call interface for runtime PSCI
├─ Passes control to UEFI at EL2
└─ Remains resident as EL3 handler
   │
   ▼
UEFI Firmware
├─ Initializes PCIe, USB, display (EFI FB)
├─ Reads DTBOs from SPI flash (plugin manager)
├─ Applies overlays to base DTB
├─ Discovers boot device (NVMe/eMMC/SD)
├─ Reads extlinux.conf or EFI boot entries
└─ Loads kernel, initrd, DTB → jumps to kernel
   │
   ▼
Linux Kernel
├─ Brings up CPUs, MMU
├─ Initializes platform devices from DTB
└─ Mounts rootfs, runs /sbin/init

UART debug access

All boot stages produce output on the debug UART before the kernel takes over:

Connector	Board	Baud	Levels
J29 (4-pin)	AGX Orin Devkit	115200 8N1	3.3V TTL
J14	Orin NX/Nano Devkit	115200 8N1	3.3V TTL

MB1: [MB1] Started
MB1: [MB1] DRAM training complete
MB2: [MB2] Tegra boot state machine
MB2: [MB2] Loading TF-A
TF-A: NOTICE: BL31: v2.7(debug):
UEFI: NVIDIA UEFI Firmware v1.0
UEFI: Loading kernel from /boot/extlinux/extlinux.conf
[    0.000000] Booting Linux on physical CPU 0x0000000000 [0x412fd050]

If the UART goes silent at a specific stage, that stage is where the failure is occurring.

UEFI customization

Viewing UEFI menu

Hold any key during the UEFI countdown (visible on UART or HDMI during development) to enter the UEFI setup menu. The menu shows boot order, secure boot settings, and platform configuration.

Device tree overlays via UEFI plugin manager

The plugin manager applies DTBOs from SPI flash. To add an overlay:

# In your machine .conf or layer local.conf:
TEGRA_PLUGIN_MANAGER_OVERLAYS:append = " my-carrier-board.dtbo"

After building, flash only the DTBO partition (no full reflash needed):

# From the L4T host tools directory:
sudo ./flash.sh --no-flash jetson-agx-orin-devkit mmcblk0p1
sudo python3 tegraflash.py \
    --chip 0x23 \
    --cmd "write esp my-carrier-board.dtbo"

extlinux.conf — kernel boot configuration

/boot/extlinux/extlinux.conf on the rootfs:

TIMEOUT 30
DEFAULT primary

MENU TITLE Jetson Orin

LABEL primary
      MENU LABEL primary kernel
      LINUX /boot/Image
      INITRD /boot/initrd
      FDT /boot/dtb/tegra234-p3701-0000-p3737-0000.dtb
      FDT_OVERLAYS my-overlay.dtbo
      APPEND ${cbootargs} root=/dev/mmcblk0p1 rw rootwait \
             console=ttyTCU0,115200 console=tty0 \
             nvidia-drm.modeset=1

Common kernel cmdline parameters for Jetson:

Parameter	Effect
console=ttyTCU0,115200	Kernel output to debug UART
console=tty0	Kernel output to HDMI
nvidia-drm.modeset=1	Enable NVIDIA DRM modesetting (required for Wayland)
isolcpus=3	Remove CPU 3 from scheduler for RT use
rootwait	Wait for rootfs device to appear (required for NVMe)
systemd.log_level=debug	Verbose systemd output

Add a kernel parameter without reflashing

# Edit extlinux.conf on the running device
sudo nano /boot/extlinux/extlinux.conf

# Add your parameter to the APPEND line
# Reboot to apply
sudo reboot

Partition layout for boot components

Partition	Contents	Updated by
MB1_BCT	Boot Control Table	flash.sh
mb1	MB1 binary	flash.sh
mb2	MB2 binary	flash.sh
mb2-applet	MB2 runtime applet	flash.sh
cpu-bootloader	TF-A + UEFI combined	flash.sh
esp	EFI System Partition (DTBOs, extlinux.conf)	flash.sh or manual copy
kernel	Linux kernel Image	flash.sh or apt
kernel-dtb	Base DTB	flash.sh
APP / APP_b	Rootfs A/B	flash.sh or OTA

For UEFI shell recovery when the system fails to boot, see Jetson UEFI shell assertion and boot recovery. For configuring device tree overlays in the Yocto build system, see Yocto BSP setup for Jetson Orin with meta-tegra.

FAQ

What are MB1 and MB2 on Jetson Orin?

MB1 runs from ROM at power-on, initializes DRAM, and loads MB2. MB2 sets up power rails, clocks, and security domains, then loads TF-A and UEFI. Both are NVIDIA proprietary binaries flashed to QSPI NOR flash partitions during flash.sh.

Can I modify the kernel command line on Jetson Orin?

Yes. Edit /boot/extlinux/extlinux.conf on the running system and add parameters to the APPEND line. Changes take effect on the next reboot with no reflashing required.

How does Jetson Orin load device tree overlays at boot?

UEFI reads DTBOs from SPI flash via the plugin manager and applies them to the base DTB before passing it to the kernel. List overlays in TEGRA_PLUGIN_MANAGER_OVERLAYS in your Yocto build; they are written to SPI flash during flash.sh.

How do I see MB1 and MB2 boot output on Jetson Orin?

Connect a 3.3V TTL UART adapter to the debug serial connector at 115200 baud. All boot stages — MB1, MB2, TF-A, UEFI, kernel — produce output on this UART.

---
