Jetson camera works with v4l2-ctl but fails to launch argus_camera — debug guide

The V4L2-works, Argus-fails failure mode is one of the most common Jetson camera bring-up issues because it’s easy to misread as a hardware problem when it’s purely a device tree metadata problem. V4L2 needs only CSI/VI hardware configuration. Argus needs additional software metadata — sensor dimensions, pixel format, clock rates — to initialize its ISP pipeline. Both read from device tree, but different nodes.

Key Insights

• V4L2 and Argus use different DT nodes — V4L2 uses the sensor and VI/NVCSI hardware nodes; Argus additionally requires tegra-camera-platform
• sensor_modes must match V4L2 format exactly — if active_w × active_h × pixel_t doesn’t match what V4L2 reports, Argus fails at mode selection
• LIBARGUS_ENABLE_LOGS=1 is mandatory for debugging — without it, Argus failures produce only Failed to create capture session with no root cause
• physical_w and physical_h in mm are required — Argus uses physical sensor dimensions for ISP calibration; missing or zero values cause silent failures
• The sensor_modes cil_settletime must be non-zero — a zero value causes NVCSI timing errors that appear during Argus but not V4L2 capture

The two-stack architecture

v4l2-ctl path:
  Sensor I2C driver → VI/NVCSI DT nodes → /dev/videoN → v4l2-ctl
  ↑ Works if CSI/VI config is correct

argus_camera path:
  Sensor I2C driver → VI/NVCSI DT nodes → /dev/videoN
                    ↓
              tegra-camera-platform node (Argus-specific)
                    ↓
              libargus / argus_daemon
                    ↓
              ICameraProvider → ICaptureSession
  ↑ Fails if tegra-camera-platform is missing or sensor_modes are wrong

Diagnosing with LIBARGUS_ENABLE_LOGS

# Always enable logs before running argus_camera
LIBARGUS_ENABLE_LOGS=1 argus_camera 2>&1 | tee /tmp/argus_debug.log

# Also useful: verbose logging
LIBARGUS_ENABLE_LOGS=3 argus_camera 2>&1 | head -100

# Key log entries to look for:
grep -E "sensor|mode|failed|error|tegra.camera|CameraProvider" /tmp/argus_debug.log

Common failure log messages and their causes:

Log message	Root cause
No cameras available	tegra-camera-platform node missing from DT
Failed to get sensor modes	sensor_modes node missing under camera module in DT
Sensor mode is incompatible	active_w/active_h/pixel_t don’t match V4L2 format
Failed to create capture session	Any of the above, or argus_daemon not running
Invalid sensor mode	cil_settletime = "0" or missing clock fields

The tegra-camera-platform node

This node lives in the device tree overlay alongside your sensor node:

/ {
    tegra-camera-platform {
        compatible = "nvidia, tegra-camera-platform";

        /* Global parameters — size these to your pipeline */
        num_csi_lanes = <4>;
        max_lane_speed = <1500000>;
        min_bits_per_pixel = <10>;
        vi_peak_byte_per_pixel = <2>;
        vi_bw_margin_pct = <25>;
        max_pixel_speed = <7680000>;
        isp_peak_byte_per_pixel = <5>;
        isp_bw_margin_pct = <25>;

        modules {
            module0 {
                status = "okay";
                badge = "imx219_topleft";      /* unique identifier */
                position = "topleft";           /* display position */
                orientation = "1";

                drivernode0 {
                    status = "okay";
                    pcl_id = "v4l2_sensor";
                    /* Path to your sensor I2C node in DT */
                    sysfs-device-tree = "/sys/firmware/devicetree/base/i2c@3160000/imx219@10";
                    is_silicon = "1";
                };
            };
        };
    };
};

The sensor_modes table

Each sensor_mode entry maps to an Argus capture mode. The fields must match your actual sensor output:

/* In the sensor node itself (not tegra-camera-platform) */
imx219@10 {
    /* ... other fields ... */

    mode0 {    /* Argus mode index 0 */
        num_lanes     = "4";
        tegra_sinterface = "serial_a";
        phy_mode      = "DPHY";
        discontinuous_clk = "no";
        dpcm_enable   = "false";
        cil_settletime = "100";          /* MUST be non-zero */

        /* These must match v4l2-ctl --get-fmt-video output exactly */
        active_w      = "1920";
        active_h      = "1080";
        pixel_t       = "bayer_rggb10";  /* match pixelformat */

        readout_orientation = "0";
        line_length   = "3448";          /* active_w + horizontal blanking */
        inherent_gain = "1";
        mclk_multiplier = "25.0";
        pix_clk_hz    = "182400000";     /* pixel clock from datasheet */

        min_gain_val  = "1.0";
        max_gain_val  = "16.0";
        min_hdr_ratio = "1";
        max_hdr_ratio = "1";
        min_framerate = "30.000000";
        max_framerate = "30.000000";
        min_exp_time  = "34";
        max_exp_time  = "550385";
    };
};

Cross-checking sensor_modes against V4L2

# Step 1: Get V4L2 format info
v4l2-ctl -d /dev/video0 --list-formats-ext
# Note: width, height, pixel format

# Step 2: Get exact frame byte count
v4l2-ctl -d /dev/video0 \
  --set-fmt-video=width=1920,height=1080,pixelformat=RG10 \
  --stream-mmap --stream-count=1 --stream-to=/tmp/test.raw

wc -c /tmp/test.raw
# For RG10 (BAYER RAW10): 1920 * 1080 * 2 = 4,147,200 bytes
# If size doesn't match, active_w or active_h in sensor_modes is wrong

# Step 3: Run Argus with matching mode
# If mode 0 fails, try mode 1, 2 etc.
LIBARGUS_ENABLE_LOGS=1 argus_camera --sensor-id=0

Quick checklist for V4L2-works, Argus-fails

1. tegra-camera-platform node exists in DT and status = "okay"
2. modules/module0/drivernode0/sysfs-device-tree path is correct (verify with ls on the running system)
3. sensor_modes/mode0/active_w and active_h match V4L2 reported resolution
4. sensor_modes/mode0/pixel_t matches V4L2 pixel format (bayer_rggb10, yuv_uyvy8, etc.)
5. cil_settletime is non-zero
6. argus_daemon is running: systemctl status argus-daemon
7. No LIBARGUS errors in journalctl -u argus-daemon

For the broader Argus camera driver documentation, see Argus API and camera driver setup on Jetson. For nvargus crash and deadlock debugging after session creation succeeds, see nvargus crash and CaptureScheduler deadlock debugging.

FAQ

If v4l2-ctl works on my Jetson camera, why does argus_camera fail?

V4L2 only needs CSI/VI hardware configuration. Argus additionally requires a tegra-camera-platform device tree node with a sensor_modes table matching the V4L2 pixel format. A working V4L2 camera with a missing or mismatched tegra-camera-platform node will fail for Argus every time.

What does argus_camera ‘Failed to create capture session’ mean?

Missing tegra-camera-platform node, no matching sensor modes, zero physical_w/physical_h, or argus_daemon not running. Enable LIBARGUS_ENABLE_LOGS=1 to see the specific failure point.

What is the tegra-camera-platform node and why does Argus need it?

An NVIDIA-specific DT node with sensor metadata — physical dimensions, sensor modes, clock rates — that Argus uses to configure the ISP. V4L2 doesn’t use it; Argus cannot function without it.

How do I find the correct sensor_modes values for my camera?

From the sensor datasheet: active pixel dimensions, pixel clock, horizontal blanking (for line_length). Verify by cross-checking raw frame byte count from v4l2-ctl against active_w * active_h * bytes_per_pixel.

---
