GMSL YUV422 capture and FORCE_FE errors on Jetson Orin — debug guide

GMSL YUV422 capture problems on Jetson trace almost exclusively to a mismatch between what the MAX9296 deserializer outputs on the MIPI bus and what the Jetson NVCSI driver expects. The partial-frame symptom — top portion valid, bottom black — is the signature of a per-line byte count mismatch: the CSI receiver thinks each line is shorter than it actually is and closes frames early.

Key Insights

• YUV422 8-bit outputs 2 bytes per pixel — vs RAW8’s 1 byte per pixel at the same resolution; the CSI configuration must account for this
• The FORCE_FE register forces a Frame End on the MIPI output — when configured, the deserializer inserts an end-of-frame marker after a fixed pixel count; if this doesn’t match the sensor output, frames are truncated
• MEDIA_BUS_FMT_UYVY8_1X16 is the correct format enum for YUV422 8-bit in the Jetson camera DT
• MAX9296 data type register must be set to 0x1E for YUV422 — the default (RAW12 = 0x2C) will cause the MIPI receiver to misinterpret the data
• dmesg crc error or force-fe triggered confirms the deserializer output doesn’t match NVCSI expectations

The YUV422 bandwidth math

At 1920×1080:

• RAW12: 1920 × 1080 × 12 bits = 24.9 Mbytes/frame
• YUV422 8-bit: 1920 × 1080 × 16 bits = 33.2 Mbytes/frame

For the same framerate, YUV422 requires ~33% more lane bandwidth. A 4-lane GMSL2 link at 3Gbps/lane can sustain 1080p60 in YUV422 comfortably. The issue is not bandwidth — it’s the data type mismatch in the MIPI header.

MIPI data type configuration on MAX9296

The MAX9296 transmits a MIPI CSI-2 packet header with a Data Type field on every line. The Jetson NVCSI uses this header to determine how to parse incoming data.

MIPI CSI-2 Short Packet Header:
[ Virtual Channel | Data Type | Word Count | ECC ]
                    ─────────
                    0x2C = RAW12 (default MAX9296)
                    0x1E = YUV422 8-bit  ← must set this
                    0x1F = YUV422 10-bit

Setting the correct data type in the MAX9296 (via I2C on the serializer/deserializer):

/* MAX9296 I2C writes to configure YUV422 8-bit output */
/* Register 0x0313 = DATA_TYPE_SEL for PIPE_X */
i2c_write(max9296_addr, 0x0313, 0x5E);   /* YUV422 8-bit, VC=0 */

/* Register 0x031C = MIPI output format for pipe X */
i2c_write(max9296_addr, 0x031C, 0x1E);   /* 0x1E = YUV422 */

/* Verify PIPE_X is configured for 8-bit YUV */
i2c_read(max9296_addr, 0x0313, &val);
/* val should be 0x5E */

In the MAX9296 kernel driver (max9296.c), these registers are typically set in the max9296_set_pipe_settings function. If using a vendor-provided driver that hardcodes RAW12, you need to patch the register write sequence.

Device tree configuration for YUV422

/* In your camera module node */
&i2c_camera {
    your_sensor@42 {
        compatible = "your-sensor";
        reg = <0x42>;

        /* This must match the deserializer data type output */
        sensor_modes {
            mode0 {
                num_lanes     = "4";
                tegra_sinterface = "serial_a";
                phy_mode      = "DPHY";
                discontinuous_clk = "no";
                dpcm_enable   = "false";
                cil_settletime = "0";

                active_w      = "1920";
                active_h      = "1080";
                pixel_t       = "yuv_uyvy8";          /* YUV422 format */
                readout_orientation = "0";
                line_length   = "2200";
                inherent_gain = "1";
                mclk_multiplier = "25";
                pix_clk_hz    = "297000000";
                min_gain_val  = "1";
                max_gain_val  = "16";
                min_hdr_ratio = "1";
                max_hdr_ratio = "1";
                min_framerate = "30";
                max_framerate = "30";
                min_exp_time  = "34";
                max_exp_time  = "550385";
            };
        };
    };
};

/* tegra-camera-platform media bus format override */
&cam_i2cmux {
    drivernode0 {
        pcl_id = "v4l2_sensor";
        /* Override default RAW12 with YUV422 */
        physical_w = "5.095";
        physical_h = "4.930";
    };
};

The pixel_t = "yuv_uyvy8" entry is critical — it sets the MEDIA_BUS_FMT_UYVY8_1X16 bus format in the Tegra camera platform, which controls what NVCSI expects.

Diagnosing the partial frame issue

# 1. Check dmesg for MIPI framing errors
dmesg | grep -E "nvcsi|crc|force.fe|overflow|frame.start" | tail -30

# 2. Capture a test frame and check the frame size
v4l2-ctl -d /dev/video0 \
  --set-fmt-video=width=1920,height=1080,pixelformat=UYVY \
  --stream-mmap --stream-count=1 --stream-to=/tmp/frame.raw

# YUV422 8-bit frame should be exactly:
# 1920 * 1080 * 2 = 4,147,200 bytes
ls -la /tmp/frame.raw
# If size is ~2MB (half), you have a RAW8 config on a YUV422 stream

# 3. Check what pixel format the driver reports
v4l2-ctl -d /dev/video0 --get-fmt-video
# Should show UYVY or YUYV, not RG10/BA10

# 4. Read the MAX9296 data type register over I2C
i2cget -y 2 0x48 0x0313
# Expected: 0x5e (YUV422 8-bit)
# If: 0x5f (RAW12) → this is the root cause

FORCE_FE register usage

The FORCE_FE register on MAX9296 is sometimes used to work around sensors that don’t generate proper MIPI end-of-frame packets:

/* MAX9296 register 0x01CE: FORCE_FE_TIMEOUT */
/* Set to 0 to disable forced frame end (let sensor control it) */
i2c_write(max9296_addr, 0x01CE, 0x00);

/* If sensor requires FORCE_FE, set timeout to match frame period:
   For 1080p30, frame period = ~33ms = 33000µs */
i2c_write(max9296_addr, 0x01CE, 0x04);  /* unit-specific, check MAX9296 datasheet */

Forcing frame end at the wrong time produces the partial frame symptom even with correct data type configuration.

For the complete GMSL2 camera bring-up workflow including MAX9295/MAX9296 initialization sequence, see GMSL2 camera bring-up on Jetson Orin with MAX9295/MAX9296. For GMSL serializer comparison and use case guidance, see GMSL2 vs FPD-Link III on Jetson — SerDes comparison.

FAQ

What is a FORCE_FE error in GMSL camera capture on Jetson?

A MIPI protocol error where the deserializer inserts a forced Frame End marker that doesn’t align with the actual frame data length. Caused by a mismatch between the deserializer output format (YUV422) and the CSI receiver configuration (RAW8/RAW12).

Why does GMSL YUV422 capture show only the top portion of the frame?

The deserializer is outputting YUV422 (2 bytes/pixel) but the driver expects RAW8 (1 byte/pixel). The CSI receiver closes the frame after half the data arrives, producing a partial image.

How do I configure MAX9295/MAX9296 for YUV422 output on Jetson Orin?

Set MAX9296 register 0x031C to 0x1E (YUV422 data type), set the DT pixel format to yuv_uyvy8, and verify MEDIA_BUS_FMT_UYVY8_1X16 is in the tegra-camera-platform node.

What dmesg messages indicate a GMSL MIPI framing error?

nvcsi: vc0 crc error, nvcsi: force-fe triggered, vi: frame start timeout, and vi: overflow error.

---
