GMSL2 camera bring-up on Jetson Orin: MAX9295/MAX9296 setup

Bringing up a GMSL2 camera on Jetson Orin for the first time is a multi-step process that requires getting both hardware initialization and the software stack right before a single frame appears. The MAX9295 serializer and MAX9296 deserializer need to establish a link, the virtual channels need to be configured, and the V4L2 driver stack needs to see the sensor correctly. This post covers the full first-time setup sequence.

Key Insights

• GMSL2 bring-up has a fixed sequence: power → link lock → I2C tunnel → address reassignment → MIPI config → first frame
• Skip any step and the next one will fail with a misleading error
• The Jetson NVCSI is downstream of the deserializer, treat it exactly like a direct-attach CSI camera once the SerDes is configured
• NVIDIA provides reference bring-up scripts for devkit combinations; custom carrier boards need DTS modifications before any of those scripts work
• dmesg | grep -i max929 and dmesg | grep -i nvcsi in sequence tells you exactly which layer is failing

The bring-up sequence, in order

GMSL2 camera bring-up on Jetson Orin is a fixed six-step sequence. Every step depends on the previous one completing successfully. The most common mistake is jumping ahead, testing MIPI output before confirming I2C tunnel, for example, and then spending hours debugging the wrong layer.

Step 1: Power. The MAX9296A deserializer needs stable VDD (1.8V) and VDDIO (1.8V or 3.3V) before anything else. The PWDNB pin must be driven high (or pulled high) to bring the chip out of power-down mode. On the camera side, the MAX9295A serializer needs its own VDD from the carrier board or from the camera module.

Step 2: Link lock. Once both chips are powered, the link training starts automatically. The MAX9296A drives the lock signal on the coax; the MAX9295A responds. This takes 5–50 ms. Read register 0x0013 on the MAX9296A, bit 3 should be 1. If it is not, link lock has failed and nothing downstream will work.

Step 3: I2C tunnel. With the link locked, the I2C tunnel is active. The deserializer forwards I2C transactions from the host to the serializer side. Verify by running i2cdetect on the camera I2C bus, you should see the MAX9295A at 0x40 and the sensor at its default address.

Step 4: Address reassignment. For multi-camera designs, each MAX9295A must be assigned a unique I2C address before individual sensor access is possible. This is done sequentially: enable link 0 only, reassign its serializer address, disable link 0, enable link 1, reassign, and so on. The kernel driver handles this if the DTS is correct.

Step 5: Sensor initialization. With unique addresses assigned, write the sensor initialization register sequence. For IMX390 or similar, this means writing the full register table for the desired resolution and frame rate mode.

Step 6: MIPI output. Configure the MAX9296A’s MIPI output (lane count, data rate, virtual channel mapping) to match what the Jetson NVCSI expects. This is done by the kernel driver based on the DTS configuration. Once set, the deserializer starts forwarding frames to the NVCSI.

Device tree requirements for Jetson Orin

The DTS for a GMSL2 camera on Jetson Orin has a specific structure. The NVCSI node references the deserializer output port, and the deserializer node contains the serializer and sensor as child nodes.

/* tegra234-camera-gmsl2-imx390.dts */

#include <dt-bindings/clock/tegra234-clock.h>
#include <dt-bindings/gpio/tegra234-gpio.h>

/ {
    tegra-camera-platform {
        compatible = "nvidia, tegra-camera-platform";
        modules {
            module0 {
                badge = "imx390_gmsl2";
                position = "front";
                orientation = "1";
                drivernode0 {
                    pcl_id = "v4l2_sensor";
                    devname = "imx390 2-001a";
                    proc-device-tree = "/proc/device-tree/i2c@31c0000/max9296@48/max9295@40/imx390@1a";
                };
                drivernode1 {
                    pcl_id = "v4l2_lens";
                };
            };
        };
    };
};

&i2c3 {
    max9296@48 {
        compatible = "maxim,max9296";
        reg = <0x48>;
        csi-mode = "2x4";
        max-src = <2>;
        reset-gpios = <&tegra_aon_gpio TEGRA234_AON_GPIO(AA, 0) GPIO_ACTIVE_LOW>;

        ports {
            port@0 {
                reg = <0>;
                max9296_gmsl0_in0: endpoint@0 {
                    remote-endpoint = <&max9295_gmsl0_out0>;
                    link-frequency = /bits/ 64 <1500000000>;
                };
            };
            port@1 {
                reg = <1>;
                max9296_csi_out0: endpoint {
                    remote-endpoint = <&nvcsi_in0>;
                    data-lanes = <1 2 3 4>;
                };
            };
        };

        max9295@40 {
            compatible = "maxim,max9295";
            reg = <0x40>;
            nvidia,gmsl-dser-device = <&max9296>;

            port@0 {
                reg = <0>;
                max9295_gmsl0_out0: endpoint {
                    remote-endpoint = <&max9296_gmsl0_in0>;
                };
            };

            imx390@1a {
                compatible = "sony,imx390";
                reg = <0x1a>;
                sensor_model = "imx390";
                physical_w = "5.37";
                physical_h = "3.02";
                sensor_modes {
                    mode0 {
                        num_lanes = "4";
                        mclk_khz = "37125";
                        pix_clk_hz = "594000000";
                        link_freq_hz = "1500000000";
                        csi_pixel_bit_depth = "12";
                        active_w = "1920";
                        active_h = "1080";
                        framerate = "30000";
                    };
                };
            };
        };
    };
};

Diagnostic sequence

When GMSL2 bring-up fails, work through these checks in order rather than jumping to MIPI debugging:

# 1. Check link lock
sudo i2cget -y 3 0x48 0x13  # MAX9296A register 0x0013
# Bit 3 = 1 → locked, 0 → not locked

# 2. Check I2C tunnel — scan for devices on camera I2C bus
sudo i2cdetect -y 3
# Should show 0x40 (MAX9295A) and 0x1a (IMX390 or your sensor)

# 3. Check kernel driver probe
sudo dmesg | grep -i "max929\|gmsl"
# Should show probe success messages

# 4. Check NVCSI
sudo dmesg | grep -i nvcsi
# Should show no errors

# 5. Test capture
gst-launch-1.0 nvarguscamerasrc sensor-id=0 ! \
  'video/x-raw(memory:NVMM),width=1920,height=1080' ! \
  nvvidconv ! xvimagesink -e

If step 1 fails, the problem is power or cable. If step 2 fails with the link locked, the I2C tunnel is misconfigured. If step 3 shows probe failure, the device tree is wrong. If step 4 shows uncorr_err, the MIPI lane count or data rate is mismatched.

Common GMSL2 bring-up errors

max9296 probe failed in dmesg

The deserializer driver can’t reach the chip. Check that VDD is stable, PWDNB is high, and the I2C bus number in the DTS matches the actual bus the chip is wired to. Confirm with i2cdetect -y <bus> before touching the DTS.

max9295 probe failed / no devices on camera I2C bus

Link lock hasn’t been established. The I2C tunnel only operates over a locked GMSL2 link. Go back to step 1, read register 0x0013 on the MAX9296A and confirm bit 3 is set.

uncorr_err in nvcsi or camrtc-capture-vi logs

MIPI data rate or lane count mismatch. The MAX9296A’s MIPI output is configured for a different data rate or number of lanes than the Jetson NVCSI expects. Check link_freq_hz in the sensor DTS node against the MAX9296A register configuration. Also verify data-lanes count in the deserializer output port matches the physical lane count from the serializer.

nvarguscamerasrc no cameras available after driver probe succeeds

The sensor driver loaded but the libargus camera stack can’t enumerate the sensor. This is usually a tegra-camera-platform DTS node issue, a missing or incorrectly named proc-device-tree path in the module definition. Check that the path points to the actual sensor node location in /proc/device-tree/.

Frames arrive for 5–10 seconds then drop to zero

GMSL2 link instability, usually from a marginal cable or connector. The link re-trains after a momentary error, causing a brief capture gap that looks like a pipeline stall. Check the cable for damage, reduce cable length if possible, and verify the MAX9296A’s equalization settings match the cable characteristics. ECC error counts in the MAX9296A registers will increase steadily before the link drops.

Custom carrier board vs devkit bring-up

Bring-up on a custom carrier board is materially different from bring-up on an NVIDIA devkit. On the devkit, NVIDIA provides tested overlays for supported camera modules, bring-up is applying the right overlay and running a validation script.

On a custom carrier board, you need to write the full DTS from scratch. The key differences:

	Devkit	Custom carrier board
DTS	Apply NVIDIA overlay	Write from scratch
I2C bus	Fixed (documented)	Depends on your schematic
PWDNB / reset GPIO	Pre-wired	Must match your schematic
NVCSI port routing	Fixed in NVIDIA DTS	Depends on PCB layout
MIPI lane assignment	Documented by NVIDIA	Depends on trace routing

The most common mistakes on custom boards: using the devkit GPIO numbers for PWDNB and reset (they’re different), using the wrong I2C bus number, and mismatching NVCSI port to physical MIPI lanes. All of these fail silently at different stages of the bring-up sequence.

If you’re bringing up GMSL2 on a custom carrier board and hitting the link lock stage reliably but failing at NVCSI or V4L2, the GMSL camera driver development service covers what a scoped engagement for this kind of problem looks like.

For the GMSL2 SerDes architecture overview, see GMSL2 SerDes explained: MAX9295 and MAX9296 for Jetson bring-up. If you are bringing up GMSL2 on a custom carrier board instead of a devkit, see GMSL2 cameras on a custom carrier board: what’s different from the devkit. If the sensor requires a custom kernel driver, see how to write a custom V4L2 camera driver for Jetson Orin.

The MAX9296A datasheet with full register maps is available on the Analog Devices product page. NVIDIA’s Jetson Linux Developer Guide covers the tegra-camera-platform DTS structure in the Sensor Driver Programming Guide.

---
