How to write a V4L2 MIPI camera driver for Jetson Orin

Writing a V4L2 MIPI camera driver for Jetson Orin requires four components: the C sensor driver implementing tegra_cam_platform_sensor_ops, a device tree source (DTS) fragment with the sensor mode table and MIPI timing parameters, registration in the nvidia-kernel-oot out-of-tree module tree, and validation using v4l2-ctl before testing with Argus.

The MIPI-specific parts are in the DTS: data-lanes, link-frequencies, and the per-mode line_length, pix_clk_hz, and readout_orientation fields. The driver code itself sets up I2C, reads the chip ID register, configures the sensor via the init register sequence, and implements the set_mode, start_streaming, and stop_streaming ops. The tegra-camera-platform framework handles all NVCSI and VI configuration from the DTS mode table, your driver does not touch those registers directly.

Key Insights

• Jetson uses the tegra-camera-platform framework, not raw V4L2 subdev ops, the DTS structure and driver ops are Jetson-specific
• The sensor mode table in the DTS is as important as the C driver code, wrong timing values cause subtle streaming failures
• First goal: get any frame through the pipeline, then iterate on format, controls, and mode accuracy
• You need the sensor’s full register map including init sequences and streaming enable registers, public datasheets are rarely sufficient
• Test with v4l2-ctl before Argus to separate driver issues from Argus integration issues

Understanding the Jetson camera driver stack

Before writing a single line of code, it helps to understand what you are plugging into.

A Jetson camera driver sits at the bottom of a chain: your driver talks to the sensor via I2C, the sensor sends MIPI CSI-2 data to the NVCSI, the NVCSI feeds the VI (Video Input) capture engine, and V4L2 / Argus sits above the VI.

The tegra-camera-platform framework coordinates all of this. Your driver implements a set of ops that the framework calls during probe, stream start/stop, and mode changes. You do not directly configure NVCSI or VI, the framework does that based on your DTS mode table.

Your sensor driver (imx_custom.c)
  ↓ implements tegra_cam_platform_sensor_ops
tegra-camera-platform framework
  ↓ configures
NVCSI → VI → V4L2 / Argus

The driver skeleton

Start with the minimal driver structure:

#include <media/camera_common.h>
#include <linux/module.h>
#include <linux/i2c.h>

static int imx_custom_s_power(struct v4l2_subdev *sd, int on)
{
    /* 1. Toggle VDD, VDDIO, VANA rails */
    /* 2. Toggle XCLR (reset) GPIO — deassert for power-on */
    /* 3. Wait for sensor power-on time per datasheet */
    return 0;
}

static int imx_custom_set_mode(struct v4l2_subdev *sd, u32 val)
{
    struct camera_common_data *s_data = to_camera_common_data(sd->dev);
    /* Write register table for mode 'val' */
    return imx_custom_write_table(s_data->client,
                                  imx_custom_mode_table[val]);
}

static int imx_custom_s_stream(struct v4l2_subdev *sd, int enable)
{
    struct camera_common_data *s_data = to_camera_common_data(sd->dev);
    u8 val = enable ? 0x01 : 0x00;
    return imx_custom_write_reg(s_data->client,
                                IMX_CUSTOM_STREAM_ENABLE_REG, val);
}

static struct camera_common_sensor_ops imx_custom_sensor_ops = {
    .numfmts       = ARRAY_SIZE(imx_custom_fmts),
    .fmts          = imx_custom_fmts,
    .power_on      = imx_custom_power_on,
    .power_off     = imx_custom_power_off,
    .s_stream      = imx_custom_s_stream,
    .set_mode      = imx_custom_set_mode,
    .g_frame_interval = imx_custom_g_frame_interval,
    .s_frame_interval = imx_custom_s_frame_interval,
};

The register write function is typically a straightforward I2C transfer. Use the camera_common infrastructure (camera_common_i2c_write) rather than raw i2c_transfer, it handles retry logic that sensor initialization sequences often need.

The mode table

The mode table is the most time-consuming part to get right. Each mode defines the sensor’s MIPI output timing for a given resolution and frame rate. Wrong values cause uncorr_err from the NVCSI or off-by-one frame rate.

The critical values, get these from the sensor datasheet, not by guessing:

mode0 {    /* 1920x1080 @ 30fps */
    mclk_khz            = "24000";     /* Input clock frequency */
    num_lanes           = "4";          /* MIPI data lanes */
    tegra_sinterface    = "serial_a";   /* NVCSI interface */
    vc_id               = "0";          /* Virtual channel */
    discontinuous_clk   = "no";
    dpcm_enable         = "false";
    cil_settletime      = "0";
    active_w            = "1920";       /* Active pixel width */
    active_h            = "1080";       /* Active pixel height */
    mode_type           = "bayer";
    pixel_phase         = "rggb";       /* Bayer pattern — check datasheet */
    csi_pixel_bit_depth = "10";         /* RAW10, RAW12, etc. */
    line_length         = "2200";       /* Total line length in pixels */
    inherent_gain       = "1";
    mclk_multiplier     = "20.0";       /* PLL multiplier from MCLK */
    pix_clk_hz          = "480000000";  /* Pixel clock = line_length × rows × fps */
    min_gain_val        = "1";
    max_gain_val        = "16";
    min_framerate       = "1.0";
    max_framerate       = "30.0";
    min_exp_time        = "28";         /* In microseconds */
    max_exp_time        = "33000";
    embedded_metadata_height = "0";
};

The pix_clk_hz must be consistent with line_length, frame height, and frame rate: pix_clk_hz = line_length × (active_h + vblank) × framerate. Get this from the sensor PLL register table in the datasheet.

Sensor register tables

Sensor init sequences are typically long arrays of (address, value) pairs. Structure them as:

static struct reg_8 imx_custom_mode_1920x1080_30fps[] = {
    /* Streaming disable */
    {0x0100, 0x00},
    /* PLL settings for 24MHz MCLK, 4-lane, 960Mbps */
    {0x0301, 0x05},
    {0x0303, 0x02},
    /* ... many more registers ... */
    /* Streaming enable */
    {0x0100, 0x01},
    {IMX_TABLE_END, 0x00},
};

The table ends with a sentinel value (IMX_TABLE_END) that the write function uses to stop. Write a simple loop that processes the table entry by entry:

static int imx_custom_write_table(struct i2c_client *client,
                                   const struct reg_8 *table)
{
    int err;
    while (table->addr != IMX_TABLE_END) {
        err = camera_common_i2c_write(client, table->addr, table->val);
        if (err)
            return err;
        table++;
    }
    return 0;
}

Testing progression

Do not try to get a perfect frame immediately. Work through this progression:

1. Driver probes. dmesg | grep imx_custom shows probe success. If probe fails, fix the DTS compatible string, I2C address, or GPIO/regulator references.

2. V4L2 device appears. v4l2-ctl --list-devices shows your sensor. If absent, the VI-to-NVCSI link in the DTS is wrong.

3. Format sets without error. v4l2-ctl --set-fmt-video=width=1920,height=1080,pixelformat=RG10 exits cleanly.

4. Streaming starts. v4l2-ctl --stream-mmap --count=10 captures frames without timeout. Any frame, even a corrupted one, means the pipeline is working.

5. Frame is valid. Capture to file and view with a RAW image viewer. Wrong Bayer pattern? Fix pixel_phase in the mode table. Wrong resolution? Fix active_w/active_h.

Implementing V4L2 controls

V4L2 controls expose sensor parameters (gain, exposure, AWB) to userspace and Argus. Register them in your probe function:

static int imx_custom_ctrls_init(struct imx_custom *priv)
{
    struct v4l2_ctrl_handler *ctrl_hdl = &priv->ctrl_handler;
    int err;

    err = v4l2_ctrl_handler_init(ctrl_hdl, 4);
    if (err)
        return err;

    /* Exposure in microseconds */
    priv->exposure = v4l2_ctrl_new_std(ctrl_hdl, &imx_custom_ctrl_ops,
        V4L2_CID_EXPOSURE, IMX_MIN_EXPOSURE_US,
        IMX_MAX_EXPOSURE_US, 1, IMX_DEFAULT_EXPOSURE_US);

    /* Analog gain (sensor-specific units, converted in s_ctrl) */
    priv->gain = v4l2_ctrl_new_std(ctrl_hdl, &imx_custom_ctrl_ops,
        V4L2_CID_ANALOGUE_GAIN, IMX_MIN_GAIN,
        IMX_MAX_GAIN, 1, IMX_DEFAULT_GAIN);

    return ctrl_hdl->error;
}

In s_ctrl, translate V4L2 values to sensor register format:

static int imx_custom_s_ctrl(struct v4l2_ctrl *ctrl)
{
    struct imx_custom *priv = container_of(ctrl->handler,
                                            struct imx_custom, ctrl_handler);
    switch (ctrl->id) {
    case V4L2_CID_EXPOSURE:
        return imx_custom_set_exposure(priv->client, ctrl->val);
    case V4L2_CID_ANALOGUE_GAIN:
        return imx_custom_set_gain(priv->client, ctrl->val);
    }
    return -EINVAL;
}

Argus calls s_ctrl during auto-exposure computation. If the exposure or gain registers write fails, Argus silently falls back to fixed values, check dmesg for write errors if AE doesn’t converge.

Building and loading the driver module

For JetPack 6 (L4T R36), use the nvidia-kernel-oot build system:

# Clone the out-of-tree kernel module repository
git clone https://github.com/NVIDIA/nvidia-kernel-oot.git
cd nvidia-kernel-oot

# Add your driver files
cp /path/to/imx_custom.c drivers/media/i2c/
# Add to drivers/media/i2c/Kconfig:
#   config VIDEO_IMX_CUSTOM
#       tristate "Custom IMX sensor"
#       depends on I2C && VIDEO_V4L2
# Add to drivers/media/i2c/Makefile:
#   obj-$(CONFIG_VIDEO_IMX_CUSTOM) += imx_custom.o

# Build
make -C . \
    KDIR=/usr/src/linux-headers-$(uname -r) \
    CONFIG_VIDEO_IMX_CUSTOM=m

# Load
sudo insmod drivers/media/i2c/imx_custom.ko
dmesg | tail -20  # Check for probe success or error

To load automatically at boot, copy the .ko to /lib/modules/$(uname -r)/extra/ and run sudo depmod -a, then add the module name to /etc/modules.

Driver probe troubleshooting

probe failed with -ENODEV

The driver is trying to read the sensor chip ID register and getting the wrong value (or no response). Either the I2C address is wrong, the sensor isn’t powered, or the I2C bus number in the DTS is wrong. Verify with i2cdetect -y <bus> that the sensor responds at the expected address before debugging the driver.

probe failed with -EINVAL or -EPROBE_DEFER

A regulator or GPIO reference in the DTS is unresolved. -EPROBE_DEFER means a dependency (PMIC, GPIO expander) hasn’t probed yet, this usually self-resolves at boot. -EINVAL means the DTS reference is wrong. Check dmesg | grep -i "imx_custom\|regulator\|gpio" for the specific resource that failed.

Driver probes but v4l2-ctl --list-devices doesn’t show the sensor

The V4L2/media device registration failed. This is almost always a tegra-camera-platform DTS node issue, the proc-device-tree path in the module definition doesn’t match the actual sensor node path. Verify by running ls /proc/device-tree/i2c@*/ and confirming the path matches what your DTS declares.

uncorr_err in nvcsi logs during streaming

MIPI data rate or lane count mismatch between pix_clk_hz/link_freq_hz in the DTS and what the sensor is actually outputting. Recalculate pix_clk_hz = line_length × (active_h + vblank) × fps using the sensor’s actual PLL configuration register values. See V4L2 uncorr_err on Jetson: what it means and how to fix it.

If the driver development is taking longer than expected or you are working with an undocumented sensor, the Jetson camera driver development service covers custom driver engagements for unusual sensors and custom carrier boards.

NVIDIA’s complete sensor driver programming guide for Jetson is in the Jetson Linux Developer Guide. Reference driver source code (IMX390, IMX219) is in the L4T kernel source at kernel/nvidia/drivers/media/i2c/.

---
