Jetson Orin silent GPU hang under sustained compute — host1x debug

Silent GPU hangs on Jetson Orin are distinct from application crashes — the process stays alive, tegrastats shows high GPU utilization, and your compute pipeline simply stops making progress with no error message. The root cause in most reported cases is a host1x interrupt servicing stall: the GPU command FIFO fills up because the driver’s interrupt handler is not running promptly enough, triggering a timeout recovery that resets the GPU state.

Key Insights

• Silent hang ≠ crash — check if your CUDA process is still alive in ps aux; if alive and stuck in a CUDA call, it’s a hang, not a crash
• host1x channel timeout in dmesg confirms the stall path — if you see this, the GPU driver triggered a recovery sequence
• JP 6.2.2 reduces but may not eliminate the issue — upgrade first; measure improvement before looking for other workarounds
• IRQ affinity matters — if the host1x interrupt is sharing a core with high-frequency other IRQs, latency spikes can trigger timeouts; pin it to a dedicated core
• Unified memory workloads are most vulnerable — large unified memory allocations (typical in LLM/vLLM) trigger more host1x DMA activity than discrete allocations

Identifying a GPU hang

# 1. Check if the CUDA process is alive
ps aux | grep your_compute_app
# If alive and CPU usage is low but GPU is high → hang

# 2. Check tegrastats
tegrastats --interval 500
# GR3D_FREQ shows 95-100% but your benchmark has stalled
# EMC_FREQ is also high (DMA traffic ongoing)

# 3. Check dmesg for host1x events
dmesg | grep -E "host1x|gk20a|nvgpu|fifo|timeout|hung|gpu" | tail -30

# Common hang signatures:
# "host1x: gk20a: channel 1: timeout"
# "nvgpu: fifo error"
# "host1x: channel X job timed out after 10000ms"

# 4. Check if nvtop shows the hang
sudo apt install nvtop
nvtop
# MEM% and GPU% stuck at 100% with no change → confirmed hang

host1x interrupt affinity

Moving the host1x IRQ to a dedicated CPU core reduces contention:

# Find the host1x IRQ number
grep -E "host1x|tegra" /proc/interrupts | head -20

# Example output shows IRQ 123 for host1x
# Set affinity to CPU 2 (bitmask 0x4)
echo 4 > /proc/irq/123/smp_affinity

# Also set GPU interrupt affinity
grep -E "nvidia|gk20a|nvgpu" /proc/interrupts
# Set those to the same core
echo 4 > /proc/irq/<gpu_irq>/smp_affinity

Make persistent across reboots with a systemd service:

# /etc/systemd/system/irq-affinity.service
[Unit]
Description=Set host1x and GPU IRQ affinity
After=multi-user.target

[Service]
Type=oneshot
ExecStart=/usr/local/bin/set-irq-affinity.sh
RemainAfterExit=yes

[Install]
WantedBy=multi-user.target

Timeout tuning

The default host1x job timeout is 10 seconds. For workloads that legitimately take longer (large model inference), increase the timeout:

# Check current timeout
cat /sys/kernel/debug/host1x/*/timeout
# or
cat /sys/module/nvgpu/parameters/jobstate_timeout_ms

# Increase to 60 seconds
echo 60000 > /sys/module/nvgpu/parameters/jobstate_timeout_ms

This prevents the driver from incorrectly triggering a recovery on legitimately long-running kernels.

Recovery from a GPU hang

When a hang occurs, the host1x driver triggers a GPU reset and attempts to recover the channel:

# The driver recovery log looks like:
# nvgpu: gr: gr recovery started
# nvgpu: mm: mmu fault
# nvgpu: fifo reset runlist 0

# After recovery, the CUDA context is invalid
# The safest recovery is to restart the application
sudo kill -9 $(pidof your_compute_app)

# If the driver did not recover cleanly, rmmod and modprobe the GPU driver
sudo rmmod nvgpu
sudo modprobe nvgpu

Upgrading to JetPack 6.2.2

# Verify current JetPack version
cat /etc/nv_tegra_release
# Should show R36 REVISION: 5.0 for JP 6.2.2

# If on older version, upgrade via SDK Manager or apt (if NVIDIA apt repo is configured)
sudo apt update
sudo apt upgrade

# Check for nvgpu driver version
modinfo nvgpu | grep version

For general GPU utilization monitoring tools on Jetson, see Jetson Orin high RAM usage at idle which covers tegrastats and jtop usage. For CUDA-accelerated LLM inference workloads that can trigger this issue, see Running LLMs on Jetson Orin.

FAQ

What is a silent GPU hang on Jetson Orin?

The GPU stops processing CUDA work — kernels don’t complete — but the process stays alive and no error is raised. Caused by a host1x interrupt servicing stall where the GPU command FIFO fills and the driver triggers a timeout recovery.

What is host1x on Jetson Orin?

The hardware bus coordinating DMA and interrupt delivery for all Jetson accelerators. GPU work is submitted through host1x channels; completion interrupts come back through host1x. Interrupt stalls here cause GPU hangs.

How do I confirm a GPU hang is caused by host1x on Jetson Orin?

Look for host1x: channel X job timed out or nvgpu: fifo error in dmesg, combined with tegrastats showing 100% GR3D utilization and no application progress.

Has NVIDIA addressed the host1x stall bug in JetPack 6.x?

JetPack 6.2.2 includes mitigation for the most common case (mixed CUDA + unified memory workloads). Upgrade to JP 6.2.2 first. Persistent cases may require IRQ affinity tuning or job timeout adjustments.

---
