Hardware design mistakes that cause Jetson carrier board bring-up failures

Most custom Jetson carrier board bring-up failures trace back to hardware design decisions made weeks before the board arrived. Power sequencing violations, EEPROM configuration errors, and PCB routing mistakes all produce software symptoms that make them look like driver problems. This post covers the hardware mistakes we see repeatedly.

Key Insights

• Most Jetson carrier board bring-up failures we debug trace back to a small set of repeatable hardware design mistakes
• Power sequencing violations (SYS_RESET* timing) are the most common single cause — and the hardest to diagnose without a scope
• ODMDATA mismatches produce silent failures: peripherals that appear missing when they are actually misconfigured
• Inverted MIPI P/N pairs look like driver bugs but are PCB routing errors — fixable in software on Orin without board rework
• EEPROM absence or wrong address causes subtle BSP behavior that doesn’t produce obvious error messages

Why hardware design mistakes look like BSP bugs

When a custom Jetson carrier board fails to bring up correctly, the first instinct is to blame the BSP or the device tree. This is usually wrong. The most common failures we encounter come from the hardware side — and they produce software symptoms that make them look like software problems.

A power rail that rises too quickly makes the module boot inconsistently. An ODMDATA mismatch makes USB disappear. An inverted MIPI lane makes camera bring-up look like a driver failure. None of these show a clear “hardware fault” error message. The engineer chases BSP configuration for days before the scope comes out and the real problem becomes obvious.

Here are the design mistakes we see repeatedly.

Mistake 1: SYS_RESET* timing violations

The Jetson module requires SYS_RESET* to stay asserted (low) for at least 1 ms after VDD_IN is stable. If SYS_RESET* rises too quickly — because it is pulled up through a low-value resistor or connected to a reset IC with an aggressive timeout — the module enters an undefined state.

The symptom: the board boots sometimes and not others. Or it always boots but hangs at a different point in the boot sequence. Or it boots but peripherals are unreliable.

The check: probe SYS_RESET* and VDD_IN simultaneously on a scope. SYS_RESET* must stay low for at least 1 ms after VDD_IN crosses its nominal voltage. If SYS_RESET* is rising before VDD_IN settles, or within 1 ms of VDD_IN stable, fix the reset circuit timing.

This also applies to modules with VIN_PWR_BAD_N: if this signal asserts during normal operation due to a wrong pull-up value or voltage divider, the module performs a hard reset unexpectedly.

Mistake 2: ODMDATA not matching carrier board

ODMDATA is a 32-bit value flashed to the module’s QSPI that tells the BSP how the carrier board is configured. The wrong ODMDATA means the BSP configures the wrong set of peripherals for the physical hardware.

Common mismatches:

• Boot device bit set to eMMC when the carrier board uses NVMe
• USB mode bits wrong, causing USB3 ports not to enumerate
• Camera configuration bits wrong, causing NVCSI ports to be disabled

The symptom of an ODMDATA mismatch is a peripheral that is completely absent from the OS (lsusb shows nothing, lspci shows nothing) with no error message. The BSP did not fail to configure it — it never tried, because ODMDATA told it the peripheral was not there.

Fix: use NVIDIA’s odmdata configuration tool to set the correct value for your carrier board and reflash. Verify the flashed ODMDATA with cat /proc/device-tree/chosen/nvidia,odmdata | xxd.

Mistake 3: carrier board EEPROM absent or wrong address

The Jetson BSP reads the carrier board EEPROM (at I2C address 0x57 by default) to determine which device tree to load. A wrong board ID in the EEPROM loads the wrong DTS — enabling wrong peripherals, disabling correct ones.

An absent EEPROM produces EEPROM Read Fail in the early serial output. The module still boots, but the BSP falls back to a default configuration that may not match your carrier board.

An EEPROM populated with all zeros (factory default, never programmed) produces the same effect as an absent EEPROM — the board ID is zero, which typically maps to a devkit configuration.

The fix: program the carrier board EEPROM with the correct board ID, SKU, and FAB revision during board assembly. Verify with sudo i2cdump -y 0 0x57 after boot.

Mistake 4: inverted MIPI P/N pairs

MIPI CSI-2 uses differential pairs for data transmission. If a PCB layout swaps the P and N lines on one or more data lanes — an easy mistake in a dense fanout — the NVCSI receives bit-inverted data on that lane.

The symptom: uncorr_err from tegra-camrtc-capture-vi on every frame. The camera probes successfully, I2C works, the sensor appears to be streaming, but every frame produces NVCSI errors. This looks exactly like a driver configuration problem.

On Jetson Orin, lane polarity inversions can be corrected in the device tree without board rework:

/* lane_polarity bitmask: bit N inverts lane N */
lane_polarity = "6";  /* Binary 0110: lanes 1 and 2 inverted */

If you have access to a logic analyzer capable of MIPI decode, you can identify which lanes are inverted by their bit patterns. If you do not, you can determine the correct bitmask by trial and error — there are only 15 non-zero possibilities for a 4-lane interface.

Mistake 5: missing or wrong PCIe reference clock

PCIe requires a 100 MHz reference clock. If the carrier board expects this clock from an external oscillator but the DTS is configured to use the Jetson’s internal clock source (or vice versa), PCIe enumeration fails. The endpoint device is powered but the link never comes up.

The check: verify whether the PCIe REFCLK on your schematic comes from the Jetson SoM or from an external oscillator on the carrier board. The DTS nvidia,refclk-select property must match.

Also check PERST# timing: PERST# must stay asserted until the reference clock is stable and VCC is settled. Asserting PERST# too early or deasserting it before the clock is stable prevents link training.

Mistake 6: wrong USB pull resistors and ID pin handling

USB3 SuperSpeed lines require proper termination. Missing or incorrect resistors on the TX/RX SuperSpeed pairs prevent USB3 link training. The device enumerates as USB2 (or not at all) with no clear error indicating why.

For USB-C connectors with CC pins: the CC pull resistors (Rd for device, Rp for host) determine the power role and connection orientation. Wrong values produce inconsistent behavior depending on cable orientation.

The ID pin on USB-A connectors must be grounded for host-mode operation. If it is left floating or pulled incorrectly, the USB controller may enter device mode unexpectedly.

For the full carrier board bring-up checklist covering all of these and more, see our custom carrier board bring-up checklist. For specific boot failure diagnosis, see Jetson carrier board not booting: 6 root causes nobody documents.

The Jetson Orin module design guide with power sequencing requirements is available on the NVIDIA developer site. The IPC2221A standard for PCB design guidelines covers impedance requirements for differential pairs.
