GMSL2 multi-camera sync on Jetson Orin: FSYNC setup guide

Synchronizing multiple GMSL2 cameras on Jetson requires hardware-level frame sync, software timestamp comparison introduces too much jitter for stereo or multi-view applications. The FSYNC signal travels through the GMSL2 control channel from Jetson to each camera, triggering simultaneous exposure across all sensors. This post covers the full synchronization setup, from DTS configuration to verifying sync is actually working.

Key Insights

• Hardware frame sync via FSYNC is the only reliable way to synchronize GMSL2 cameras, software approaches drift within seconds
• The FSYNC signal travels from Jetson GPIO → MAX9296A → GMSL2 control channel → MAX9295A → camera sensor trigger input
• Virtual channel assignment is mandatory for multi-camera setups, two cameras on the same VC corrupt both streams
• The MAX96724 quad-deserializer simplifies 4-camera designs by aggregating all streams into a single MIPI output
• Frame sync failures look like intermittent frame drops or tearing, not a complete pipeline failure, harder to diagnose

Why frame sync matters for multi-camera

If you are building a stereo, surround-view, or array camera system, unsynchronized frames are not a cosmetic problem, they cause real failures. Stereo depth estimation requires both cameras to capture the same moment in time. Surround-view stitching requires frames to align spatially. Even 10 ms of offset between cameras introduces motion artifacts that make the output unusable for most applications.

Free-running cameras, even cameras with identical settings, drift relative to each other over time because their internal oscillators have tolerance. Two cameras nominally running at 30 fps may be 16.7 ms apart (half a frame period) within a minute of start-up.

Hardware frame sync solves this by driving all cameras from a common trigger. Every camera captures on the same edge. Frame-to-frame timing error is in the microsecond range, which is acceptable for virtually any multi-camera application.

The FSYNC signal path in GMSL2

GMSL2 provides a control channel that runs bidirectionally alongside the video data. This control channel carries I2C/UART traffic and GPIO signals between the deserializer and serializer sides.

The FSYNC path for a dual-camera GMSL2 setup on Jetson Orin:

Jetson GPIO (configured as PWM or GPIO output)
  → MAX9296A FSYNC pin
    → GMSL2 control channel (both links simultaneously)
      → MAX9295A FSYNC pin (link 0)
      → MAX9295A FSYNC pin (link 1)
        → Camera sensor TRIGGER/SYNC input

This means a single Jetson GPIO triggers all cameras simultaneously. No separate wire per camera. No cable routing changes for additional cameras.

The FSYNC GPIO is configured in the DTS and the deserializer driver forwards it automatically once the link is locked.

/* Configure FSYNC GPIO in DTS */
max9296@48 {
    /* ... */
    fsync-gpios = <&tegra_aon_gpio TEGRA234_AON_GPIO(BB, 1) GPIO_ACTIVE_HIGH>;
    fsync-mode = "GMSL2";
    fsync-period = <3300000>; /* 33ms = ~30fps FSYNC period in nanoseconds */
};

Virtual channel assignment for multi-camera

The MAX9296A deserializer aggregates multiple camera streams onto a single MIPI output using MIPI CSI-2 virtual channels. Each camera gets a unique VC number.

Camera 0 → MAX9295A link 0 → MAX9296A → MIPI VC0 → NVCSI → V4L2 device 0
Camera 1 → MAX9295A link 1 → MAX9296A → MIPI VC1 → NVCSI → V4L2 device 1

The VC assignment is configured in the MAX9296A deserializer registers and must also be reflected in the DTS via vc_id:

/* Camera 0 — Virtual Channel 0 */
imx390@1a {
    sensor_modes {
        mode0 {
            vc_id = "0";
            /* ... */
        };
    };
};

/* Camera 1 — Virtual Channel 1 */
imx390@1b {
    sensor_modes {
        mode0 {
            vc_id = "1";
            /* ... */
        };
    };
};

If both cameras are on VC0, the NVCSI interleaves their data and both streams are corrupt. The failure looks like two unusable but active video streams, not a complete pipeline failure.

4-camera topology with MAX96724

For 4-camera designs on Jetson Orin, the MAX96724 quad-deserializer is the common solution. It supports 4 GMSL2 input ports and outputs 4 virtual channels over a single MIPI CSI-2 link.

Camera 0 → MAX9295A → MAX96724 port 0 → \
Camera 1 → MAX9295A → MAX96724 port 1 →  MIPI (VC0-VC3) → Jetson NVCSI
Camera 2 → MAX9295A → MAX96724 port 2 → /
Camera 3 → MAX9295A → MAX96724 port 3 → /

The MAX96724 requires a different kernel driver and DTS structure than the MAX9296A. NVIDIA’s reference drivers in L4T R36 include MAX96724 support for specific carrier board configurations.

GStreamer pipeline for synchronized multi-camera capture

Once hardware sync is working, reading all streams in GStreamer uses nvarguscamerasrc per sensor fed into nvstreammux. The NVCSI hardware timestamps each frame at the moment of capture using a shared system clock, frames triggered on the same FSYNC edge arrive at the muxer with matching timestamps, so no software alignment is needed.

gst-launch-1.0 \
  nvstreammux name=mux batch-size=2 width=1920 height=1080 \
    batched-push-timeout=4000000 live-source=1 ! \
  nvinfer config-file-path=config_infer.txt ! \
  nvmultistreamtiler rows=1 columns=2 width=3840 height=1080 ! \
  nvvidconv ! nv3dsink \
  nvarguscamerasrc sensor-id=0 ! \
    'video/x-raw(memory:NVMM),width=1920,height=1080,framerate=30/1' ! \
    nvvidconv ! mux.sink_0 \
  nvarguscamerasrc sensor-id=1 ! \
    'video/x-raw(memory:NVMM),width=1920,height=1080,framerate=30/1' ! \
    nvvidconv ! mux.sink_1

live-source=1 is important, without it, nvstreammux may block waiting for a full batch from a slow source, which introduces artificial latency. With live sources, it pushes partial batches after batched-push-timeout microseconds.

For stereo depth applications, you typically want to read frames in C++ via appsink and process them as a pair. The key is setting max-buffers=1 and drop=false on both sinks and using a mutex to collect the matching pair before dispatching to the stereo algorithm.

How to verify frame sync is working

The most direct verification is timestamp comparison across streams:

# Run both in parallel, capture 60 frames each
v4l2-ctl --stream-mmap -d /dev/video0 --stream-count=60 \
  --stream-to=/dev/null -v 2>&1 | grep "ts" > /tmp/ts0.txt &
v4l2-ctl --stream-mmap -d /dev/video1 --stream-count=60 \
  --stream-to=/dev/null -v 2>&1 | grep "ts" > /tmp/ts1.txt

# Compare corresponding timestamps
paste /tmp/ts0.txt /tmp/ts1.txt

With hardware sync, every row should show timestamps within 1ms of each other. With free-running cameras, the delta grows over time as oscillator drift accumulates.

A second verification: probe the FSYNC pin on the serializer board with an oscilloscope while the pipeline is running. You should see a clean square wave at the configured frame rate (e.g., 30Hz = 33ms period). If the pin is static, the DTS GPIO configuration is wrong or the deserializer driver isn’t forwarding the signal.

# Confirm FSYNC GPIO direction and state from software
gpioinfo | grep -A2 "BB 1"
gpioget <chip> <line>  # should toggle at frame rate if correctly configured

Diagnosing sync failures

Cameras appear to capture but timestamps diverge over time

Hardware FSYNC is not reaching the sensors. Check that the GMSL2 link is locked (dmesg | grep "link locked"), then verify the FSYNC GPIO is configured as output in the DTS. Use gpioset to manually pulse the GPIO and confirm it toggles.

One camera captures correctly, the other shows corrupted frames

Virtual channel conflict. Both cameras are sharing a VC number. Check the vc_id values in the DTS, they must be unique per camera. Also verify the deserializer register configuration matches the DTS.

All cameras drop frames after a few seconds of sync operation

FSYNC period mismatch between the configured period and what the sensor expects. If the sensor expects 30fps but FSYNC is toggling at 25Hz, it will eventually lose lock. Verify fsync-period in nanoseconds matches the target frame rate exactly.

nvarguscamerasrc fails to open sensor after adding FSYNC config

A DTS error in the FSYNC node is preventing driver probe. Check dmesg | grep max9296 for probe errors and compare the GPIO specifier against your carrier board schematic.

For complex GMSL2 bring-up problems, multi-camera with unusual serializer configurations, custom carrier boards, or mixed sensor arrays, the GMSL camera driver development service covers what a fixed-bid engagement typically involves. For the broader GMSL2 pipeline setup, see GMSL2 camera driver on Linux: V4L2, MAX9296 kernel driver, device tree.

The MIPI CSI-2 virtual channel specification is in the MIPI Alliance CSI-2 standard. The MAX9296A FSYNC configuration registers are documented in the Analog Devices MAX9296A datasheet.
